Arktek Intel H610 LGA1700 Dual Channel DDR4 Motherboard

Features

• Intel H610
• Model: AK-H610MB EG
• Socket: LGA1700
• Chipset: Intel H610
• Processor Support: Supports Intel Socket LGA1700 12th/13th/14th Generation
• Processors Core I9/ i7/ i5/ i3 Processors
• Memory Support: Dual Channel DDR4 2133/2400/2800/3200MHz XMP Overclock (Max. up to 32GB each)
• On-Board Graphics: Integrated Graphics Processor-Intel HD Graphics Support
• DIMM: 2 x Memory Slots
• LAN: Realtek 8111H 100M/1000Mbps Support wake-up on LAN, PXE function
• Audio: 1x F Audio, three-in-one HD Port
• Storage: 3 x SATA 3.0 Port 1 x M.2 Port
• 1 x M.2 WIFI/Bluetooth Port

USB

• 2 x USB 3.0 Port 2 x USB 2.0 Port

External Interface

• 1 x PS2 MS/KB 1 x COM header 1 x HDMI 1 VGA
• 1 x DP 1 x 6-CH Audio

Built-In Interface

• 1 x F_USB
• 1 x USB3.0
• 1 x F_AUDIO
• 1 x J_SPK
• 1 x JCMOS
• 1 x CPU_FAN
• 1 x CSYSFAN
• 1 x PCI-E x16 Slot
• 1 x PCI-E x1 Slot
• Form Factor: Micro-ATX (22cm X 18 cm)

Accessories

• 1 x SATA Cable
• 1 x User Manual
• 1 x I/O Backboard 1X CD Driver
• OS Support: Support Windows 7 / 8 / 8.1 / 10(x64)
• Mounting: 6 Mounting Holes
